Project Breakdown

• Designed detailed wiring schematics and system diagrams in Lucidchart to define electrical architecture and interfaces
• Fabricated and routed wiring harnesses with controlled labeling, strain relief, and serviceability considerations
• Assembled electrical subsystems and validated connections through continuity testing and staged power-up checks
• Integrated sensors, actuators, and control electronics into the vehicle electrical system
• Improved system reliability through iterative refinement of routing, connectors, and wire management

Technical Stack

• Lucidchart (Wiring Schematics)
• Wiring Harness Design
• Crimping & Connectors
• Continuity Testing (Multimeter)
• Power Distribution
• Vehicle Sensors
• Actuators
• DC Electrical Systems
• Documentation & Revision Control
• Workshop Electrical Build Practices
